ZHY Series Low Pressure Pneumatic Conveying System for Fully Automatic Packaging Machine



        Zaozhuang Sunweigh  Co.,Lltd. produces a full-automatic packaging machine ZHY series low-pressure pneumatic conveying system, which uses roots blower as air source to continuously convey materials.  The equipment has beautiful appearance design, stable performance and high operation efficiency.  It is an important choice for many powdery material packaging and batching enterprises.  ZHY series low-pressure pneumatic conveying system for full-automatic packaging machines has obtained the national utility model invention patent, is a conveying system independently developed and produced by Zaozhuang Snweigh Technology Co., Ltd., and is also one of the few packaging machines manufacturers capable of producing full-automatic packaging machines low-pressure pneumatic conveying system.

     Application of ZHY Series Low Pressure Pneumatic Conveying System for Fully Automatic Packaging Machine;


This equipment can transport powder and granular materials such as casting new sand and old sand. ZHY series low pressure pneumatic conveying system is simple in structure and reliable in conveying.  It is also a conveying system of a full-automatic packaging machine specially developed and produced for powdery materials. Compared with other feeding modes such as belt feeding mode and gravity feeding mode of the full-automatic packaging machine, it has higher efficiency and more obvious dust optimization in the transportation of powdery materials.




Main technical parameters of ZHY series low-pressure pneumatic conveying system for full-automatic packaging machines:

Serial	item	unit	parameter
1	delivery mode		continuous low pressure type
2	conveying distance	m	<100
3	hoisting height	m	18
4	conveying management	mm	178*5
5	roots blower
6	motor powert	kw	40
7	production rate	t/h	15
