Spiral Feeding Full-automatic Packaging Machine

Spiral feeding automatic packaging machine is a powder automatic packaging machine specially developed for powder materials. According to the characteristics of powder materials, the automatic packaging machine of Zaozhuang Sunweigh Technology Co., Ltd. is easy to jam and stick powder materials in the process of discharging, which seriously affects the packaging speed. The screw conveying method can effectively avoid the jamming and sticking phenomenon of powder materials and realize the smooth packaging of powder materials. Spiral feeding automatic packaging machine can be widely used in automatic packaging of starch, chemical industry, medicine and other powder materials.

全自动包装机



Product introduction of screw feeding automatic packaging machine



The screw feeding automatic packaging machine mainly consists of screw conveyor, automatic weighing system, bag clamping device, automatic bag loading manipulator, automatic folding machine, automatic sewing machine and conveyor. The screw feeding method can ensure the powder material's normal production and discharge, avoid the material jamming and sticking phenomenon affecting the packaging efficiency. The automatic weighing system weighs the packaging bags at all times, waiting for the weight of the packaging bags to meet the packaging requirements, and the control system automatically stops feeding. The automatic bagging manipulator automatically sets the bags at the lower outlet. The clamping device clamps the bags. When the bags are discharged, the clamping device automatically opens the bags. The conveyor conveys the bags to the folding machine for folding and sewing. Finally, the conveyor outputs the bags and waits for stacking. In the whole packaging process, the screw feeding automatic packaging machine does not need the participation of workers. The whole packaging process is completed by the automatic packaging machine independently.





Functional characteristics of screw feeding automatic packaging machine



The screw feeding automatic automatic packaging machine also aims at powder material packaging, which can effectively avoid the phenomenon of powder material sticking.
The screw feeding automatic packaging machine can realize automatic packing bag finishing, automatic opening and absorbing, automatic moving bagging, automatic weighing and measuring, counting, filling, moving output and importing automatic folding seam bag of automatic seam machine.
The packaging equipment is controlled by touch screen. It is convenient to operate, switch specifications and maintain, safe and reliable. The whole set of equipment has complete automatic detection procedures, automatic deviation correction, automatic fault detection prompts, convenient maintenance. The operation of the equipment is personalized without manual participation. The fault alarm automatically alerts the operator to the fault location, fault phenomena and fault detection and treatment methods.
Spiral feeding automatic packaging machine can automatically control the working process of automatic packaging machine production line through intelligent program control. It can realize continuous operation, has the functions of fault alarm, display and automatic interlocking shutdown. It can also be equipped with communication interface according to user's needs to realize real-time monitoring, remote diagnosis and network management of automatic packaging machine.

自动上袋机

Technical parameters of screw feeding automatic packaging machine

1. Weighing range: 20-50 kg/bag;

2. Weighing accuracy: <0.2%;

3. Packaging capacity: 200-800 packages per hour;

4. Power supply: 380VAC/220VAC 50HZ;

5. Control power supply: 24VDC;

6. Control gas source: 0.5-0.8 MPa.

Spiral feeding automatic packaging machine is a fully automatic packaging machine specializing in powder materials, so it can also be called powder automatic packaging machine. Compared with the automatic packaging machine for particulate and mixture materials, the packing speed of powder automatic packaging machine is lower than that of other materials.
