Automatic packaging production line
Automatic packaging production line is a set of automatic packaging system developed and produced by Zaozhuang Sunweigh Technology Co., Ltd for many years in accordance with the needs of many industries. Can also be called automatic packaging scale production line.
Introduction of automatic packing scale production Line
Automatic packing scale production line mainly consists of automatic bag loading machine, automatic quantitative packing scale, automatic edge folding sack closer and conveying system. The package system is mainly aimed at materials which are packed with paper bags and woven bags (coated). Automatic packing scales can be used to carry out automatic bagging of these materials, automatic weighing and packing, and automatic sealing of material packaging bags. The conveyer automatically outputs to the palletizing machine to carry on the whole bag palletizing. The whole packaging process is controlled by the PLC system and does not require the participation of workers. It saves a lot of manpower, material and financial input for the enterprise, improves the production efficiency, reduces the production cost of the enterprise, and allows the enterprise to compete in the market. It is good for the invincible position in the struggle. Automatic packing scale production line is widely used for automatic packaging of many materials, such as grain, feed, flour, starch, fertilizer, medicine, chemical industry, briquette and so on.
Functional Features of automatic Packaging scale production Line
1.The automatic bag loading machine in the automatic package scale package unit solves the problem of manual bag loading and improves the working efficiency of the packing scale. The automatic bag loading machine can automatically absorb the woven bag, then open the woven bag and automatically cover the bag at the discharge port by the entrainment clip. Automatic weighing, counting, filling, moving output, automatic edge sewing package output, the whole process is all automatic.
2, the automatic packaging scale adopts PLC control system, full touch screen control, simple operation, Easy to use. Automatic detection program, automatic fault alarm, equipment personalization operation, convenient maintenance;
3, wide range of application, you can make any Fully automatic packaging is realized with the material packed in the packing bag.
Packaging parameters of automatic packing scale production line.
First, it must be a paper bag, or a coated woven bag, double-layer composite bag;
secondly, according to different materials, different feeding methods, can package powder material, granular material, mixed material.
Third, the packing range of automatic packing scale is 20-50kg, which can be packed 200-1200 bags per hour;
fourth, the accuracy error of packing is controlled within 0.2%; fifth, the compressed air: 0.4 ~ 0.8MPa, the maximum air consumption is 1.6 m³ / min; sixth, use power supply: 6.2 Kw AC380V ±10% 50 Hz.
After-sale service of automatic packaging scale production line
1.Preventive maintenance services. We carry on the maintenance to the equipment regularly, to the possible breakdown carries on the prevention, maintains the equipment to run steadily and orderly, carries on the omni-directional maintenance and the repair to the customer's equipment operator to the customer's equipment and the spare part maintenance and repair.
2, Regular return visit service. Production and transportation optimization services during the operation of the equipment, we provide professional technical personnel to carry out regular visits to the operation of the equipment, so as to ensure the safe and stable operation of the equipment sold. Customers can conduct telephone consultation on problems that occur while the equipment is running. We are equipped with professional dispensers, the customer needs the equipment and components to the fastest, the most The safe way to the customer, at the same time for the customer to choose the lower cost transport mode, through the continuous efforts to optimize transport services. We provide customers with reliable and objective services, using modern methods, appropriate logical structure and professional approach to ensure the safety, smooth and stable operation of our equipment.
